Whiteman Ride-on Power Trowel JWN
Reference:
€15,000.00
VAT excluded
JWN24HTCSL
Secure Payments
Fast Shipping
Customer Satisfaction
JWN24HTCSL
The JWN is a non-overlapping twin rotor 36-inch (914mm) ride-on trowel. Features like a constantly variable transmission, twin pitch control and a durable GX690 Honda engine will enable this model to deliver years of trouble free service.
Drive system
- Equipped with a GX690,24HP,Honda V-Twin gasoline engine and construction grade driveline that enables rotor speed ranges from 40-180 rpm
- Variable transmission continuously adjusts the drive ratio to obtain optimum torque and rotor speed
- Fan-cooled high capacity gearboxes extend service life
Design
- Entry level trowels offer increased value at an affordable price
- Non-overlapping blades can be used with float pans
- Spider assemblies feature long lasting wear plates and spider hubs and can be economically rebuilt. Standard model comes with 4 blade configuration
Operating controls
- Patented steering assist makes controlling the machine remarkably easy and reduces operator fatigue
- Retardant spray system and LED lights
Engines using gasoline or LPG fuel should be operated only in areas with adequate ventilation. NEVER operate in confined areas or in areas where the free flow of air is restricted.
| Engine | Honda GX 690 Gasoline, 22.1 HP | |
| Engine Cooling | Air | |
| Blades per Rotor | 4 | |
| Rotor RPM | 0-180 | |
| Path Width | 75 in | 1905 mm |
| Fuel Tank Capacity | 5 gal | 18.9 L |
| Run Time | 1.71 gal/hr | |
| Overall Length | 77 in | 1955 mm |
| Overall Width | 39 in | 990 mm |
| Overall Height | 50 in | 1270 mm |
| Operating Weight | 741 lb | 336 kg |
| Shipping Weight | 960 lb | 435 kg |
